G2200E X-TRA

The electric mini loader G2200E X-TRA has a lifting capacity of 2,200 kg, a lift height of 2.45 meters, and is specially developed for extremely heavy-duty work and tasks in construction and earthmoving. The wheel loader combines the best of both worlds with the advantages of an articulated loader and virtually silent operation with no emissions. Therefore, the G2200E X-TRA is ideal for working in buildings or on construction sites in urban areas.

g2200e x tra tobroco giant
elektrische mini shovel batterij

No emissions

Electrical motor

Equipped as standard with a 260 Ah, 48V lithium-ion battery

Choice of various types of safety roofs

Choose the roof structure that suits your tasks

ROPS / FOPS safety roof
ROPS / FOPS foldable safety roof
ROPS / FOPS foldable safety roof deluxe
ROPS / FOPS Cabine
Choice of various attachments

Select the right attachment for your tasks

Pallet fork
Earth bucket
Stone bucket
High volume bucket
Choice of various types of tires

Select the right tires for your tasks

10.0 75-15.3 AS
27x10.50-15 SKID
29x12.50-15 GRASS
31x15.50-15 AS
31x15.50-15 X-TRAC
Hydraulic Quick Hitch
Double acting valve at the front (mechanical)
ROPS / FOPS safetyroof incl. safety doors left and right
Hydraulic servicebrake on 4 wheels
Luxury seat with safetybelt, armrest and extended backrest
Towing hook at the back
Working light (LED) at the front
Battery management system
Anti-theft protection with access code (not certified)

The G2200E X-TRA comes standard with a 260 Ah, 48V lithium-ion battery that can be easily charged with the on-board charger (390 Ah and 520 Ah batteries are optional). The separate electric motors, 7 kW for propulsion and 12 kW for hydraulic work, always provide sufficient power to perform tasks precisely. Furthermore, the machine regenerates energy when rolling out or descending a hill.

Specifications
Service weight 1 2200 kg
Lifting capacity 2200 kg
Tipping Load 2 2054 kg
Lifting height 3 2450 mm
Length without bucket 3054 mm
Machine height 4 2300
Width on standard tires 1080 mm
Standard tires 10.0/75x15.3 AS
Travel Speed 0-18 km/h
Electric motor 6,5 kW
Energy recuperation Machine recuperates energy when it rolls out or drives downhill
Type Electric four wheel drive with cardan shaft
Differential Axles with limited slip
Pulling force 12500
Hill-Hold control Automatic brake prevents rolling back on a slope
Parking brake Drum brakes

1Measured with earthbucket

2Measured with counterweight and driver ± kg

3Measured with counterweight and driver ± kg

4ᶟ Measured on standard tyres with safety roof

Attachments for G2200E X-TRA More Attachments
