G3500 TELE
With a lift height of over 4.3 meters, the G3500 TELE is perfect for tasks at height. The compact dimensions allow the machines to operate in small spaces and even indoors.
Choice of various types of safety roofs
Choose the roof structure that suits your tasks
Choice of various attachments
Select the right attachment for your tasks
Choice of various types of tires
Select the right tires for your tasks
Lifting arm
GIANT hydraulic quick change system
ROPS / FOPS safetyroof incl. safety doors left and right
Luxury air suspended seat with safety belt, armrest and extended backrest
Double acting valve at the front (mechanical)
Modular cylinder option (MCO)
Transport securing device
Hose rupture protection on lift cylinder
Hydraulic servicebrake on 4 wheels
Working light (halogen) at the front
Battery, 77 Ah
Main switch
Anti-theft protection with access code (not certified)
Towing hook at the back
1 Counterweight integrated into the bumper
Cyclone filter
Oil cooler
The hydrostatic 4-wheel drive with automotive steering and 100% switchable differential lock on both 14-ton axles prevent the machine from losing grip and provide sufficient pulling force for smooth movement. The articulated-pendulum system gives the G3500 TELE stability and maneuverability. The system ensures that all four wheels stay on the ground, even when working on uneven terrain. This not only makes it safe to work but also ensures sufficient traction.
Specifications
Service weight
1
4000 kg
Lifting capacity
2500 kg
Tipping Load
2
2500 kg
Lifting height
3
4312 mm
Length without bucket
4067 mm
Machine height
4
2275
Width on standard tires
1340 mm
Standard tires
11.5/80-15.3 AS
Travel Speed
0-10 km/h 0-30 km/h (with automatic gear)
Engine
Kubota V2403-CR-TE5B DOC/DPF (STAGE V)
Cylinders
4
Engine power
66 hp
Engine power (kW)
48,5
Fuel tank capacity
68 l
Oil tank capacity
60 l
Type
Hydrostatic 4 wheel drive
Transmission
Automotive control
Differential
100% electrical differential lock on both axles
Final drive
14 tons axles with heavy planetary end drive
Pulling force
39000
Pulling force standard
39000 N
Driving hydraulics
112 l/min (450 bar)
Working hydraulics
70 l/min (220 bar)
Parking brake
Drum brakes
1Measured with earthbucket
2Measured with counterweight and driver ± kg
3Measured with counterweight and driver ± kg
4ᶟ Measured on standard tyres with safety roof
