G5000 Z-HEF
The compact and agile G5000 machines are the epitome of productivity, comfort and longevity. Whether working in agriculture, construction & demolition, infrastructure or other fields of application. Thanks to its various configurations, the G5000 is widely applicable.
![g5000balenvork[1]](https://configurator.tobroco-giant.com/files/Machines/G5000/G5000_bundel_bestanden/g5000balenvork[1].jpg "g5000balenvork[1]")
![g5000grondbak[1]](https://configurator.tobroco-giant.com/files/Machines/G5000/G5000_bundel_bestanden/g5000grondbak[1].jpg "g5000grondbak[1]")
GIANT hydraulic quick change system
ROPS/FOPS safety roof incl. rear window and safety doors (L+R)
Luxury air suspended seat with safety belt, armrest and extended backrest
Double acting hydraulic function on lifting arm (mechanical)
Floating position on lifting cylinder(s)
Hydraulic servicebrake on 4 wheels
Working light (halogen) front, on lifting arm
Main switch
Anti-theft protection with access code (not certified)
Tow coupling
Counterweight integrated into the bumper
Cyclone filter
Oil cooler
Tipping loads of the machine
The table shows the tipping loads at different positions of the machine. The tipping load is the maximum weight the machine can lift while remaining stable and not tipping. The actual tipping load depends on the configuration of the machine, such as various options, attachments and working position.
Specifications
Service weight
1
5200 kg
Lifting capacity
2800 kg
Tipping Load
2
3507 kg
Lifting height
3
3500 mm
Length without bucket
4165 mm
Machine height
4
2523
Width on standard tires
146 mm
Standard tires
11.5/80-15.3 AS
Travel Speed
0-10 km/h, 0-20 km/h (with automatic gear) Optional 0-35 km/h
Engine
Kubota V3307-CR-TE (Stage V) with DOC and DPF
Cylinders
4
Engine power
75 hp
Engine power (kW)
55
Fuel tank capacity
77
Oil tank capacity
80 l
Type
Hydrostatic 4 wheel drive
Transmission
Automotive control
Differential
100% electrical differential lock on both axles
Final drive
16 tons axles with heavy planetary end drive
Pulling force standard
39000 N
Pulling force 2 speed
60000 N
Driving hydraulics
145 ltr/min (480 bar)
Working hydraulics
78 ltr/min (250 bar)
Parking brake
Hydraulic multidisc brake SAHR
1Measured with earthbucket
2Measured with counterweight and driver ± kg
3Measured with counterweight and driver ± kg
4ᶟ Measured on standard tyres with safety roof
