G2300 HD

The GIANT G2300 HD resembles the G2200 and features a 4-cylinder engine. The wheel loader can be customized according to preferences due to the numerous available options.

Download brochure here

g2300hd tobroco giant
Choice of various types of safety roofs

Choose the roof structure that suits your tasks

ROPS / FOPS safety roof
ROPS / FOPS foldable safety roof
ROPS / FOPS Cabine
Choice of various attachments

Select the right attachment for your tasks

Pallet fork
Earth bucket
Stone bucket
High volume bucket
Choice of various types of tires

Select the right tires for your tasks

10.0/75x15.3 AS
27x10.50-15 SKID
29x12.50-15 GRASS
31x15.50-15 AS
31x15.50-15 X-TRAC
ROPS / FOPS safetyroof incl. safety doors left and right
Mechanically suspended seat incl. safety belt and armrest
Double acting valve at the front (mechanical)
Floating position on lifting cylinder(s)
Hydraulic servicebrake on 4 wheels
Working light (halogen) at the front
Main switch
Rear tow coupling
Cyclone filter
Oil cooler
Specifications
Service weight 1 2300 kg
Lifting capacity 1650 kg
Tipping Load 2 1595 kg
Lifting height 3 2825 mm
Length without bucket 3065 mm
Machine height 4 2300
Width on standard tires 1080 mm
Standard tires 10.0/75x15.3 AS
Travel Speed 0-10 km/h 0-20 km/h
Engine Kubota D1505 (STAGE V)
Cylinders 4
Engine power 26 hp
Engine power (kW) 19
Fuel tank capacity 37 l
Oil tank capacity 56 l
Type Hydrostatic 4 wheel drive
Transmission Automotive control
Differential Limited slip on both axles
Final drive 8 tons axles (Heavy Duty)
Pulling force 23000 N
Driving hydraulics 65 l/min (360 bar)
Working hydraulics 40 l/min (210 bar)
Parking brake Drum brakes

1Measured with earthbucket

2Measured with counterweight and driver ± kg

3Measured with counterweight and driver ± kg

4ᶟ Measured on standard tyres with safety roof
