GS800G

The GS800G is the most compact powerhouse and is very suitable for narrow indoor spaces. The machine has simple controls and tyres can easily be changed on site. This gives the machine a width of 75 cm to 110 cm. The 21 hp petrol engine provides a 4 wheel drive with strong pulling and pushing force and a lifting capacity of 576 kg.

2260 sk252dside
Choice of various types of safety roofs

Choose the roof structure that suits your tasks

Choice of various attachments

Select the right attachment for your tasks

Pallet fork
Earth bucket
Stone bucket
High volume bucket
Choice of various types of tires

Select the right tires for your tasks

22x11-8 All ground
5,00-8 Forklift
5,00-12 AS
23x8.50-12 AS
23x8.50-12 SKID
1x double acting function at the front 36 L/min
Adjustable hip bracket
Single-side hydraulic hold on first double acting function
Parallel guidance on lifting arm
Counterweight integrated into the mudguards
Height-adjustable, sprung driver’s plateau
Hand throttle
Oil cooler
Lifting eyes
Specifications
Service weight 1 750 kg
Lifting capacity 576 kg
Tipping Load 2 461 kg
Lifting height 3 2060 mm
Length without bucket 1675 mm
Width on standard tires 1090 mm
Standard tires 22x11-8 All Ground
Travel Speed 0-6 km/h
Engine Honda GX630
Cylinders 2
Engine power 21 hp
Engine power (kW) 15,5
Fuel tank capacity 21 L l
Oil tank capacity 42 L l
Final drive 2 heavy Parker wheel engines
Working hydraulics 36 L/min (180 bar)

1Measured with earthbucket

2Measured with counterweight and driver ± kg

3Measured with counterweight and driver ± kg
